Converting Length Units

Warning: Your screen size is quite small for viewing this. Rotate your device into landscape mode if you can.

1 Getting Started
2 Watch the Digits Move
3 Watch and Notice
4 Try It Together
5 Chain the Conversions in Your Copy
6 Class Challenge
7 What Did We Notice?
8 What's Next
Pupil practice

1 - Getting Started ~4 mins

Illustration for Getting Started Here is a builder's measurement: a wall is 4.7 metres long. The builder needs to write that same length in centimetres for the plan. How many centimetres is 4.7 m? Have a quick estimate before we work it out together.

Teacher Notes

Take two or three hands-up estimates, not open call-outs. Don't confirm yet, we'll check it on the ladder in a moment. If a pupil says "multiply by 100", revoice it as a question to the class: why 100 and not 10?

👇 Mark your steps as done as you complete them.

+5 XP

2 - Watch the Digits Move ~7 mins

Before we use the ladder, look at what happens to the digits. To change 4.7 m into centimetres, there are 100 centimetres in every metre, so we multiply by 100. Watch each digit slide two columns to the left. The decimal point does not move, the digits do.

So 4.7 m becomes 470 cm. The number got bigger because a centimetre is smaller than a metre, so it takes more of them to make the same length.

Teacher Notes

Point at the place-value columns as each digit steps left. Say it slowly: the 4 was in the ones, now it sits in the hundreds; the 7 steps from the tenths into the tens. The single idea to land here is the digits move, the decimal point stays put. This grid is the why; the ladder steps that follow are the practice.

👇 Mark your steps as done as you complete them.

+10 XP

3 - Watch and Notice ~9 mins

4.7 m to 470 cm to 4,700 mm

Now watch the ladder. From metres down to centimetres we multiply by 100 (×100). From centimetres down to millimetres we multiply by 10 (×10). Each step down to a smaller unit makes the number bigger.

250 mm to 25 cm to 0.25 m

Now we go the other way, up the ladder to bigger units. From millimetres up to centimetres we divide by 10 (÷10). From centimetres up to metres we divide by 100 (÷100). Going up makes the number smaller. Watch the decimal appear.

0.085 km to 85 m to 8,500 cm

This one starts in kilometres, our biggest unit. From kilometres down to metres we multiply by 1000 (×1000). From metres down to centimetres we multiply by 100 (×100). Watch how the same length looks very different depending on which unit we choose.

Teacher Notes

Walk each example one at a time, pointing at the ladder rungs and naming the factor for each rung-jump.

4.7 m → 470 cm (×100) → 4,700 mm (×10) — confirm the hook estimate here. Notice the two steps use different factors.
250 mm → 25 cm (÷10) → 0.25 m (÷100) — going up divides; watch the decimal appear.
0.085 km → 85 m (×1000) → 8,500 cm (×100) — the small decimal trips pupils up; emphasise that km is the biggest unit, so its number is the smallest.

Keep naming the factor (×10, ×100 or ×1000) before each step lands, so the class hears which rule applies to which rung-jump.

+10 XP

4 - Try It Together ~7 mins

Today we work through this conversion together on the ladder: 1.5 km all the way down to millimetres. We tap one rung at a time and say the factor out loud before each step lands: ×1000 from km to m, ×100 from m to cm, then ×10 from cm to mm.

1.5 km along the ladder

Teacher Notes

This round is for talking it through together. Pupils take turns at the board and the class agrees or corrects out loud.

Run the first pass in guided mode: tap the destination rung and the digits slide while the matching factor chip pulses. Name each factor as it lands: ×1000, then ×100, then ×10. Then switch to explore mode and invite individual pupils up to tap any rung and name the factor before the digits land. Watch for the pupil who tries to "move the decimal point", redirect to the digits move, the point stays.

+15 XP

5 - Chain the Conversions in Your Copy ~5 mins

COPYBOOK MOMENT

In your maths copy, work each conversion as a chain. Draw an arrow between each step and label it with the factor you used.

2 km → ? m → ? cm → ? mm
3.5 m → ? cm → ? mm

Write ×10, ×100 or ×1000 on each arrow.

Teacher Notes

Walk the room glancing at the labels on the arrows, this is whole-class copybook practice, not marking. The arrow-labels are the bit that matters: a chain with no factors written on is the slip to catch. Note that the two chains use different factors at each rung, so pupils must think about each step rather than reuse one rule.

+10 XP

6 - Class Challenge ~8 mins

Today we hit these conversions on the ladder: 50 mm to cm, 4 cm to mm, 6 m to cm, 2.5 km to m, then the big chain, 3 km all the way down to millimetres. The chain takes three steps in a row, ×1000 from km to m, then ×100 from m to cm, then ×10 from cm to mm, so we'll say each step aloud before we check it.

Convert along the ladder

Teacher Notes

This round is the practice bank. Pupils take turns at the board, check each answer, and the class confirms before moving on. Keep the board work brisk rather than over-explaining.

On the multi-step chain (3 km → mm), the learner fills every rung in between, so let the class predict each rung before Check marks it, and name the factor each time (×1000, ×100, ×10). Watch for pupils stopping one step short on the chain. Use the on-screen ✓ as part of the narration, yes, that's it.

+15 XP

7 - What Did We Notice? ~3 mins

MATHS TALK

Going from kilometres down to millimetres took three steps, first ×1000, then ×100, then ×10. What does that tell us about how the units fit inside each other? If 3 km becomes 3,000,000 mm, why is the millimetre number so much bigger?

Teacher Notes

Listen for pupils naming the chain as three separate steps with different factors (km→m is ×1000, m→cm is ×100, cm→mm is ×10). Revoice a strong answer: so the smaller the unit, the more of them you need to make the same length. Head off the idea that bigger number means longer thing, the length never changed, only the unit did.

+10 XP

8 - What's Next ~3 mins

What we did today

Converted between mm, cm, m and km using ×10, ×100 and ×1000
Saw the digits slide left for smaller units and right for bigger units, with the decimal point staying put
Chained conversions one step at a time, all the way from km down to mm, with a different factor at each rung

Coming up

Next we'll use these length skills on real shapes, adding all the sides of a polygon to find the perimeter.

Teacher Notes

Quick recap. Keep the focus on the rule pupils can carry forward: smaller unit means multiply, bigger unit means divide, and check which factor each rung-jump needs.

+5 XP

Pupil practice

Module 4 · Measures: Length, Mass, Capacity, Area, Volume Measures

Lesson 48 · Converting Length Units

Download Activity Book page (PDF)

End of lesson
